Product Information:
- Voltage: 24V
- Nominal Airflow: 303 m³/h
- This heat exchanger has a 3-speed fan
- Heating Capacity (ethylene glycol): 5.35 kW
- 4 x Ø60 mm Air Sleeves for even air distribution
- Glycol Connection: Ø16 mm
- Maximum Allowable Internal Temperature: 100°C
- Maximum Usable Internal Temperature with Autoterm Flow Series Heater (°C): 88
For fan speed control, ATFR018 is recommended, which is a 4-position switch.
- 4-pin connector ATFR051 is available separately (not included with the heater).
The water heat exchanger is suitable for all of the following heaters:
- Autoterm Flow 5 B / D
- Autoterm Flow 14d
- Manufacturer: Siroco
It is a heat exchanger that functions as a radiator with an active fan and 4 x Ø60 mm air connections for even air distribution to up to 4 rooms. It is possible to use airflow adapters to distribute warm air to more rooms (depending on room size and insulation).
Since this water heat exchanger can operate independently without an Autoterm Flow Series heater, it can be used to circulate air in the room. The heat exchanger can be connected with 4 air ducts (Part No: ATFR013) for even air distribution.
As an alternative, the heat exchanger can be connected to the engine's coolant system instead of the Autoterm Flow Series heater.
