Product information:
Voltage: 24V
Low noise fan
Nominal air flow: 110 m3/h
This heat exchanger has a 1-speed fan
Heating capacity, Ethylene glycol: 2.75 kW
Inlet & outlet for ethylene glycol: ø16 mm
Front panel of water heat exchanger is heat resistant & removable
Maximum allowable inner temperature °C: 100
Maximum reachable inner temperature with AUTOTERM Flow series heater °C: 88
* 2-pin connector kit FR052 available separately - not included in kit
Water heat exchanger with the fan is suitable for all the following liquid heaters:
Manufacturer: SIROCO
It is a heat exchanger that works as a radiator with an active fan that distributes hot air around the room it has been installed. As this water heat exchanger can run independently without AUTOTERM Flow series heater tuned on, it can be used to just to can be used to circulate air in the room. As an alternative, heat exchanger can be linked with engines coolant system instead of AUTOTERM Flow series heater.
